Bench proof · anonymized case study

From reference geometry to a finished marquise build.

A marquise reference needed production geometry that could move from the screen into a bench-built setting.

The constraints

  • Use the reference as guidance for an original build
  • Resolve the setting for metal
  • Match CAD planning to bench execution

The bench path

  1. 01Build the production CAD direction
  2. 02Use the model to guide the metalwork
  3. 03Finish the matching marquise bench result

The proof

Marquise engagement ring CAD render used to plan a custom setting.
Finished marquise ring resting at the bench after custom metalwork.

The result

The paired CAD and bench images show production planning followed by matching custom metal execution.

Services usedJewelry CAD designCustom jewelry
